Thermally Broken Bi-fold Aluminium Door
Designer Series ThermalHEART™ | Series 730
Series 730 bi-fold door incorporates ThermalHEART™ technology giving a true wide thermal break between the outside and inside faces. WERS (Window Energy Rating System) data shows that using the same IGU in a ThermalHEART™ Bi-fold door is 32% more efficient than a standard non-thermally broken Bi-fold door.
Features & Benefits
- A major advantage with ThermalHEART™ bi-fold doors in cold climates is the reduction in internal condensation. This saves potential damage to timber reveals and paint finishes. ThermalHEART™ is also suitable for hot climates.
- We offer ThermalHEART™ in a range of stocked colours including dual colour ClearMIST™, contact your local Vantage fabricator for details.
- Running bi-fold doors on bottom rollers reduces the problems caused by lintel sag and allows us to offer optional highlights.
- This bi-fold door has been tested for compliance with the relevant Australian Standards and achieved a high water resistance of 380Pa. This makes the product suitable for most residential applications.
- Low air infiltration, makes this bi-fold door suitable for airconditioned buildings.
- The extra strong door stiles on this bi-fold door allow oversize door panels to be fabricated.
- Sharp square external glazing beads are standard on this bi-fold door product.
- 100mm frame and transom have a soft 2mm internal radius.
- Series 730 bi-fold doors will accept Centor™ S1 screen.
Product specifications
- Maximum Panel Height* :2600mm
- Maximum Panel Width* :900mm
- Maximum Glass Thickness :≤ 32mm
- SHGC Range :0.13 - 0.46
Testing & Certification
- Acoustics Tested & Certified
- AS2047 Performance Tested
- BAL40 Bushfire Tested & Certified
Features Overview
Attention to detail is what sets us apart.
Learn more about the unique features and functionality of this product.
Enquire with our team for more information.
Sill Options
Bottom Rollers
Screening
Screen Sill Detail
Floor Channels
Internal Trim
Learn More
Colour & Finish
A range of modern and
classic colour options are
available to suit your
window and door selections.
View our colour options build
your dream home today!
Our hardware range
Discover our range of stylish and innovative solutions for residential and commercial windows and doors.
